JY-SP05 Wall Mount Surge Protector
CEFCCRoHSISO9001
The JY-SP05 is a compact 5-outlet surge protector that turns one wall socket into nine powered connections: five widely spaced AC outlets plus two USB-A and two USB-C ports. 1300 joules of surge protection shields everyday electronics from spikes and surges.
The 1.5-inch outlet pitch fits slightly larger adapters without blocking adjacent sockets, and the USB ports deliver 15W of combined charging (2.4A per USB-A, 3A per USB-C) for phones and tablets. A low-profile 45-degree angled flat plug keeps cords tidy against the wall without covering the second outlet, and four mounting tabs allow screw installation wherever power needs to be within reach.
Sized at just 5.91 x 3.54 inches, it works as a desktop strip, a nightstand charging station or a behind-the-TV power hub. Mount it under a kitchen cabinet, beside a workbench or in the garage — anywhere a few reliable outlets beat a tangled extension cord.
OEM/ODM customization available: logo, housing color, cord length, packaging and outlet configuration. Contact us for samples and quotations.
Specifications
| AC Outlets | 5x widely spaced, 1.5in pitch |
|---|---|
| Surge Protection | 1300 Joules |
| USB Ports | 2x USB-A (5V/2.4A max), 2x USB-C (5V/3A max), 15W / 3A total |
| Power Cord | 5ft / 1.5m, 14AWG |
| Plug | 45-degree angled flat plug |
| Mounting | Wall-mountable, 4 mounting tabs |
| Housing | UL94 V-0 flame-retardant PC+ABS, matte black |
| Rating | AC 100-250V, 50/60Hz, 15A / 1875W max |
| Dimensions | 5.91 x 3.54 x 1.10 in |
| Net Weight | 1.03 lb / 465 g |
Request a Quote
Send your target quantity and customization needs. We reply within 24 hours.
